性價(jià)比較高光功率計(jì)

Model

NBT190

Spectral Range

189nm - 10.7 µm

Maximum Power
Minimum Power

 10 W
 1 mW

Active

12 mm（Diameter）

Detector Active Area

1.13 cm²

Responsivity

0.53 mV/W

Rise Time

0.3 s

Calibration Uncertainty

±2.5 % @ 1064 nm

Power Noise Level

1 mW

Repeatability

±0.5 %

Beam Size Dependence

±0.7 %

Power Density, Maximum Average

36 kW/cm²

Pulse Energy Density, Maximum

1.0 J/cm²
